Five Core Advantages (5 “O” Highlights)

Safer

The system uses cobalt-free LiFePO₄ (Lithium Iron Phosphate) battery technology, fundamentally eliminating the thermal runaway risks associated with cobalt-based lithium batteries.
LiFePO₄ chemistry offers higher safety, longer lifespan, higher efficiency, and higher power density, supported by an intelligent Battery Management System (BMS) for comprehensive protection.

Reliable

• Supports high discharge power

• IP20 protection for battery modules and an IP55-rated cabinet for the entire system

• Natural air-cooling design for stable and efficient operation

• Wide operating temperature range ensures strong environmental adaptability

Flexible

• Modular design enables easy system expansion

• Suitable for both residential and commercial applications

• Designed to increase energy self-consumption and optimize power usage

Convenient

• Battery modules support automatic networking for simplified installation

• Remote monitoring and system upgrades supported

• Local firmware upgrades available via USB, reducing maintenance time and cost

Eco-Friendly

• Manufactured using environmentally friendly materials

• Non-toxic and non-polluting throughout the entire system lifecycle

Technical Specifications

A. Cabinet Specifications

• Rated Voltage: 358.4 V

• Rated Capacity: 280 Ah

• Dimensions (W×D×H): 1250 × 1245 × 2175 mm

• Weight: 1260 kg

• Max Charge / Discharge Current: 140 A

• Cooling Method: Air-cooled

• Protection Level: IP55

• Fire Suppression: Aerosol fire extinguishing system

B. Battery Specifications

• Battery Type: 51.2V / 280Ah LiFePO₄ modules

• Recommended Charge / Discharge Current: 100 A

• Communication Interfaces: RS485 / CAN

• Operating Temperature:

  • Charging: 0°C to 50°C

  • Discharging: –10°C to 50°C

• Storage Temperature: –20°C to 60°C

• Design Life: Over 10 years

• Cycle Life: >6000 cycles (@0.5C, 80% DOD)

• Certifications: CE, IEC, UL, UN38.3, MSDS, RoHS

C. AC-Side Specifications

• Rated Power: 50 kW

• Overload Capability: 110%

• Rated Voltage / Frequency: 400 V / 50 Hz or 60 Hz

• Communication Protocols: Ethernet / Modbus / TCP/IP

• Inverter Compatibility: Deye, Solis, Megarevo, and other mainstream inverter brands

Typical Applications

• Commercial & industrial energy storage systems

• Solar PV + battery storage projects

• Peak shaving and load shifting

• Backup power for commercial buildings and factories

• International aid and infrastructure energy projects

Why Choose Bright Solar Energy Storage Solutions?

With international certifications, global project experience in 159 countries, and proven performance in UN, NGO, and World Bank projects, Yangzhou Bright Solar Solutions Co., Ltd. delivers reliable, safe, and scalable energy storage systems for global commercial and industrial customers.
